Detail

Specification

Hydraulic Ram

SCM420 Ø37.7mm

Beam

S45C

2Pieces-Main Rod

Hex Bar 21mm X L10” X 5/8” -11NC

2Pieces-Extension Rod

Hex Bar 21mm X L10” X 5/8”-11NC

Sent pop

Ø1” X L30mm 50BV30 HRC 40˚±2

Ram Extension Rod

Ø1” X L2” S45C HRC 38˚±3

Ram Extension Rod

Ø1” X L4” S45C HRC 38˚±3

Bearing Separator

Spread Range 105-150mm

(SCM415 HRC 42˚±3)

Adapter

S45C

Packing(metal box/inner box)

2 sets/ctn, 30kgs/31kgs/0.8’
